肉条机机产品简介

Introduction meat machine products

一、用途：

A, use:

肉条机是本公司应用最先进技术研制成功的新型食品机械， 本机专业切制各种肉类，切成条、丁状，如：五花肉、牛肉等。

Strips of machine is the company using the most advanced technology to develop a new food machinery professional success, the machine cutting all kinds of meat, cut into strips, cubes, such as: pork, beef etc..

二、特点：

Two, characteristics:

①该机外形美观，结构紧凑、操作简便、工作可靠、功能齐全，维修方便、适应性强，既可单机生产也适用于大型肉类加工流水线。

This machine has the advantages of compact structure, beautiful appearance, convenient operation, reliable operation, complete function, convenient repair, strong adaptability, can be stand-alone production also applies to large meat processing production line.

②本机采用进口圆刀，切面光洁，无连刀；刀具设计合理，方便拆卸，易清洗。

The machine adopts imported round knife, cut smooth, without even a knife; tool is reasonable in design, easy disassembly, easy cleaning.

③本机凡与食物接触部分均采用优质304不锈钢制造，输送带为白色无毒橡胶带，符合卫生标准，是理想的肉类加工设备。

The machine where the food contact parts are made of high quality 304 stainless steel manufacturing, the conveying belt is a white nontoxic rubber belt, to meet the health standards, is the ideal equipment for meat processing.

备注：1、物料在0-5°状态下切制效果最大；

Note: 1, the material in the 0-5 degrees state cutting effect is the biggest;

      2、本机可将物料一次性切成规则的条状，肉条再切便成肉丁；

2, the machine can be material one-time cut into regular strips, strips cut it into diced meat;

      3、本机禁止切割带骨的肉类以及其他的硬物。

3, the prohibition of cutting machine with bone meat and other hard objects.

三、技术参数

Three, the technical parameters

1、肉条机参数

1, strips of machine parameters

①外形尺寸：1700×660×1320 mm（长×宽×高）

The dimensions: 1700 x 660 x 1320 mm (length * width * height)

②入料口尺寸：400×65 mm (宽×高)

The material inlet size: 400 x 65 mm (wide * high)

③输送带有效宽度： 400mm

The effective width of conveyer belt: 400mm

④物料切割厚度：0~65mm

The cutting material thickness: 0~65mm

⑤物料切割宽度（两片刀的刀尖距离）：15mm（标准配置为15mm，也可根据客户要求定制，0-50mm可选；）

The cutting width (tip distance two pieces of knife): 15mm (standard for the 15mm, can also be customized according to customer requirements, the optional 0-50mm;)

⑥输送带电机规格：380V/0.55KW

The conveyor motor specifications: 380V/0.55KW

⑦刀组电机规格：380V/1.5KW

The motor specifications knife group: 380V/1.5KW
